Engine

• Model: Isuzu AA-6HK1XQP

• Type: 6 Cylinder, inline, water cooled

• Rated Engine Power: 256 HP (190.5 kW) @ 2000 rpm

• Max Torque: 872.8 N·m @ 1700 rpm

• Batteries: 2 x 12V

• Displacement: 7.79 L

Control System

• Control System: DOMCS Intelligent Controller

• Control Hydraulic System: Positive Flow

• Working Modes: H, S, L, B

• Remote Monitoring System: GPRS, GPS, GIS

Hydraulic System

• Main Pumps: 2 Variable Displacement Axial Piston Pumps

• Max Flow: 2 x 316 LPM

• Pilot Pump: 1 Gear Pump

• Travel Motor: 2 Axial Piston Motors with Parking Brake

• Swing Motor: 1 Axial Piston Motor with Swing Holding Brake

Relief Valve Settings

• Implement Circuit: 34.3 MPa

• Swing Circuit: 26 MPa

• Travel Circuit: 34.3 MPa

• Pilot Circuit: 3.9 MPa

Undercarriage & Working Device

• Track Shoes (each side): 49

• Upper Rollers: 2

• Lower Rollers: 9

• Track Guard (each side): 2

• Std. Track: 600 mm

• Std. Boom: 6400 mm

• Std. Arm: 2400 mm

• Std. Bucket: 1.8 m³ GP

Performance

• Max. Travel Speed (High / Low): 5.2 / 3.4 km/h

• Swing Speed: 9.5 rpm

• Gradeability: 70% / 35°

• Ground Pressure: 62 kPa

• Max. Tracking Force: 270 kN

• Bucket Digging Force: 233 kN

• Arm Digging Force: 212 kN

Service Refill Capacities

• Hydraulic Tank: 380 L (Tank)

• Fuel Tank: 540 L

• Engine Oil: 35 L

• Radiator: 31.9 L

• Swing Device: 10.5 L

• Travel Device: 2 x 5.0 L

Cab

• AC: Std.

• Cabin Guard: Opt.

Bucket

• Capacity: 1.5 m³ HD (Opt), 1.8 m³ GP (Std), 2.0 m³ GP (Opt)
