Cummins 6BT5.9-C140

Engine

• Model: Cummins 6BT5.9-C140

• Type: 6 Cylinder, inline, water cooled

• Rated Engine Power: 140 HP (104 kW) @ 2000 rpm

• Max. Torque: 571 N·m @ 1300 rpm

• Batteries: 2 x 12V

• Displacement: 5.88 L

Control System

• Control System: DOMCS Intelligent Controller

• Control Hydraulic System: N.A

• Working Modes: H, S, L, B

• Remote Monitoring System: GPRS, GPS, GIS

Hydraulic System

• Main Pumps: 2 Variable Displacement Axial piston pumps

• Max. Flow: 2 x 220 LPM

• Pilot Pump: 1 Gear Pump

• Travel Motor: 2 Axial piston motors with parking brake

• Swing Motor: 1 Axial piston motor with swing holding brake

Relief Valve Settings

• Implement Circuit: 34.3 MPa

• Swing Circuit: 25.5 MPa

• Travel Circuit: 34.3 MPa

• Pilot Circuit: 3.9 MPa

Undercarriage & Working Device

• Track Shoes (each side): 45 / 47

• Upper Rollers: 2

• Lower Rollers: 7 / 8 (opt.)

• Track Guard (each side): 1

• Std. Track: 600 mm

• Std. Boom: 5700 mm

• Std. Arm: 2400 mm

• Std. Bucket: 1 m³ GP

Performance

• Max. Travel Speed (High / Low): 5.4 / 3.3 km/h

• Swing Speed: 11 rpm

• Gradeability: 70% (35°)

• Ground Pressure: 47.3 kPa

• Max. Tracking Force: 209 kN

• Bucket Digging Force: 138 kN

• Arm Digging Force: 129 kN

Service Refill Capacities

• Hydraulic Tank: 239 L (Tank)

• Fuel Tank: 340 L

• Engine Oil: 14 L

• Radiator: 25.2 L

• Swing Device: 4 L

• Travel Device: 2 x 5.5 L

Cab

• AC: Optional

• Cabin Guard: Optional

Bucket

• Capacity: 1 m³ GP (Std.) & 0.9 m³ HD (Opt.)
