Engine

• Make & Model: Cummins B3.9-100c

• Type: 4 Cylinder, Inline, Water Cooled

• Rated Engine Power: 100.5 HP (75 kW) @ 2200 rpm

• Max. Torque: 385 Nm @ 1300 rpm

• Battery: 2 × 12 V

• Displacement: 3.9 L

Control System

• Control System: DOMCS Intelligent Controller

• Control Hydraulic System: Positive Flow

• Working Modes: H, S, L, B

• Remote Monitoring System: GPRS, GPS, GIS

Hydraulic System

• Main Pumps: 2 Variable Displacement Axial Piston Pumps

• Max. Flow: 2 × 121 Lpm

• Pilot Pump: 1 Gear Pump

• Travel Motor: 2 Axial Piston Motors with Parking Brake

• Swing Motor: 1 Axial Piston Motor with Swing Holding Brake

Relief Valve Settings

• Implement Circuit: 31.4 MPa

• Swing Circuit: 25 MPa

• Travel Circuit: 31.4 MPa

• Pilot Circuit: 3.9 MPa

Undercarriage & Working Device

• Track Shoes (Each Side): 44

• Upper Roller (Each Side): 1

• Lower Roller (Each Side): 7

• Track Guard (Each Side): 1

• Std. Track: 500 mm

• Std. Boom: 4600 mm

• Std. Arm: 2100 mm

• Std. Bucket: 0.72 m³ (Multi-purpose Bucket)

Performance

• Max. Travel Speed (High/Low): 5.5 / 3.5 km/h

• Swing Speed: 12 rpm

• Gradeability: 70% / 35°

• Ground Pressure: 43.1 kPa

• Max. Tracking Force: 124.1 kN

• Bucket Digging Force: 93.6 kN

• Arm Digging Force: 68.9 kN

Service Refill Capacities

• Hydraulic Tank: 150 L (System), 120 L (Refill)

• Fuel Tank: 240 L

• Engine Oil: 9 L

• Radiator: 18 L

• Swing Device: 3 L

• Travel Device: 2 × 2.22 L

Cab

• AC: Optional

• Cabin Guard: Optional
