Operating Weight

• Max. Operating Weight: 17,000 ± 200 kg

• Front Axle: 5,100 kg

• Rear Axle: 11,900 kg

• Weight Without Dozer & Ripper: N/A

Engine

• Model: Cummins QSB6.7C220-30

• Rated Power: 220 HP @ 2,200 rpm

• Displacement: 6.75 L

• Cylinders: 6

• Max Torque (Net): 949 N·m @ 1,500 rpm

Powertrain

• Forward / Reverse Gears: 5F / 5R

• Transmission: Composite Power Shift

• Service Brakes: Hydraulic

• Parking Brake: Hydraulic

Operating Specifications

• Minimum Turning Radius: 7.4 m

• Steering Range (Left / Right): 50°

• Articulation Angle (Left / Right): 24°

• Oscillation of Front Axle: 16°

• Front Wheel Tilt Angle: 17°

• Travel Speed (Forward): 6 / 10 / 16 / 28 / 36 km/h

• Travel Speed (Reverse): 6 / 10 / 16 / 28 / 36 km/h

Hydraulic System

• Circuit Type: Open Hydraulic System

• Pump Type: Gear Pump

• Max System Pressure: 18 MPa

• Standby Pressure: 0.5 MPa

• Reservoir Tank Capacity: 210 L

Moldboard

• Blade Width: 3,360 / 3,965 mm

• Blade Height: 620 mm

• Blade Thickness: 22 mm

• Lift Above Ground: 480 mm

Tandem

• Make: Meritor / Equivalent

• Height: 730 mm

• Width: 210 mm

• Sidewall Thickness (Inner/Outer): 20 mm

• Drive Chain Pitch: 50.8 mm

• Wheel Axle Spacing: 1,538 mm

Service Refill Capacities

• Fuel Tank: 310 L

• Cooling System: 40 L

• Engine Oil: 22 L

• Transmission Oil: 25 L

• Tandem Housing (Each): 25 L

Tires

• Wheel & Tires: 17.5 × 25″ – 12 PR
